630-27W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 27POS R/A SLDR
| Part | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Voltage Rating | Contact Finish | Contact Finish Thickness | Number of Positions [custom] | Number of Positions [custom] | Flange Feature | Material Flammability Rating | Backset Spacing | Backset Spacing | Connector Style | Connector Type | Number of Rows [custom] | Contact Type | Mounting Type | Shell Size, Connector Layout | Shell Size, Connector Layout | Features | Termination | Current Rating (Amps) | Shell Material, Finish | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | 2 | 25 | M3 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Coax Signal | Right Angle Through Hole | 4 | 27W2 | Mounting Brackets | Solder | |||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | M3 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | 10A 5A | ||||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Housing/Shell (M3) | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | 10A 5A | Nickel Plated Steel | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | 2 | 25 | Housing/Shell (Unthreaded) | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Coax Signal | Right Angle Through Hole | 4 | 27W2 | Shielded | Solder | Nickel Plated Steel | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock | Solder | Nickel Plated Steel | 5 A 40 A | |||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | 2 | 25 | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Coax Signal | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | |||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | Housing/Shell (M3) | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | 20A 5A | Nickel Plated Steel | |||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock | Solder | 10A 5A | Nickel Plated Steel | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | Flash | M3 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | 5 A 40 A | ||||||
 EDAC Inc. | Copper Alloy | Polyester Thermoplastic | -55 C | 125 °C | Black | 125 VDC | Gold | M3 | UL94 V-0 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | 2 | Signal and Power | Right Angle Through Hole | 4 | 27W2 | Board Lock Mounting Brackets | Solder | 30 Áin | 0.76 Ám | 5 A 30 A |
