MEC1-108 Series
Standard Card Edge Connectors 1.00 mm Mini Edge Card Socket, Vertical
Manufacturer: Samtec Inc.
Catalog
Standard Card Edge Connectors 1.00 mm Mini Edge Card Socket, Vertical
Beta
⌘K
Standard Card Edge Connectors 1.00 mm Mini Edge Card Socket, Vertical
Standard Card Edge Connectors 1.00 mm Mini Edge Card Socket, Vertical
Standard Card Edge Connectors 1.00 mm Mini Edge Card Socket, Vertical
| Part | Features | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Termination | Mounting Type | Read Out | Gender | Card Thickness | Card Thickness | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Number of Positions | Contact Material | Card Type | Material - Insulation | Color | Pitch [x] | Pitch [x] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Samtec Inc. | Board Guide Pick and Place | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | |
Samtec Inc. | Board Guide Pick and Place | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 10 Áin | 0.25 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | |
 Samtec Inc. | Board Guide | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 10 Áin | 0.25 Ám | 2 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | 60 | |
Samtec Inc. | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount Right Angle | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Phosphor Bronze | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | ||
Samtec Inc. | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 30 Áin | 0.76 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | ||
Samtec Inc. | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | ||
Samtec Inc. | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Board Edge Straddle Mount | Dual | Female | 0.062 in | 1.57 mm | 10 Áin | 0.25 Ám | 2 | 16 | Phosphor Bronze | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | ||
Samtec Inc. | Board Guide Pick and Place | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | |
Samtec Inc. | Pick and Place | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm | |
 Samtec Inc. | Loop Bellows | -55 °C | 125 °C | Gold | Solder | Surface Mount | Dual | Female | 0.062 in | 1.57 mm | 3 Áin | 0.076 Ám | 2 | 16 | Beryllium Copper | Non Specified - Dual Edge | Liquid Crystal Polymer (LCP) | Black | 0.039 in | 1 mm |
