XC9136 Series

Catalog

IC REG BOOST 3.5V 500MA 10USPB

Part	Output Configuration	Package / Case	Voltage - Output (Min/Fixed) [Min]	Topology	Function	Current - Output	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Number of Outputs	Frequency - Switching	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Mounting Type	Voltage - Output (Min/Fixed)
Torex Semiconductor Ltd XC9136N35CDR-G	Positive	10-PowerUDFN	3.5 V	Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount
Torex Semiconductor Ltd XC9136N18CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	1.8 V
Torex Semiconductor Ltd XC9136E41CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	4.1 V
Torex Semiconductor Ltd XC9136N42CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	4.2 V
Torex Semiconductor Ltd XC9136N38CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	3.8 V
Torex Semiconductor Ltd XC9136E45CDR-G	Positive	10-PowerUDFN	4.5 V	Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount
Torex Semiconductor Ltd XC9136N49CDR-G	Positive	10-PowerUDFN	4.9 V	Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount
Torex Semiconductor Ltd XC9136E35CDR-G	Positive	10-PowerUDFN	3.5 V	Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount
Torex Semiconductor Ltd XC9136E25CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	2.5 V
Torex Semiconductor Ltd XC9136E47CDR-G	Positive	10-PowerUDFN		Boost	Step-Up	500 mA	2.9	2.6	10-USPB	1	1.2 MHz	85 C	-40 ¯C	5.5 V	0.65 V	Surface Mount	4.7 V
