DT-14 Series
Manufacturer: Belden Inc.
Beta
⌘K
CBL TIE LOCKING NAT 50LBS 1.187'
| Part | Width [x] | Width [x] | Mounting Type | Length - Approximate | Material | Wire/Cable Tie Type | Color | Length - Actual [x] | Length - Actual [x] | Tensile Strength | Tensile Strength | Bundle Diameter [diameter] | Bundle Diameter [diameter] | Width | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 4.57 mm | 0.18 in | Free Hanging (In-Line) | 14.25 in | Polyamide (PA) Nylon | Locking Standard | Natural | 361.95 mm | 1.187 ft | 22.68 kg | 50 lbs | 4 in | 101.6 mm | ||
Belden Inc. | 0.3 in | Free Hanging (In-Line) | 15 in | Polyamide (PA) Nylon | Locking Standard | Natural | 383.29 mm | 1.257 ft | 54.43 kg | 120 lbs | 4.06 in | 103 mm | 7.62 mm | ||
 Belden Inc. | 4.57 mm | 0.18 in | Free Hanging (In-Line) | 14.25 in | Polyamide (PA) Nylon | Locking Standard | Black | 361.95 mm | 1.187 ft | 22.68 kg | 50 lbs | 4 in | 101.6 mm | UV Resistant | |
 Belden Inc. | 0.3 in | Free Hanging (In-Line) | 15 in | Polyamide (PA) Nylon | Locking Standard | Black | 383.29 mm | 1.257 ft | 54.43 kg | 120 lbs | 4.06 in | 103 mm | 7.62 mm | UV Resistant |
