173-E15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, DB15, RECEPTACLE, 173-E M SERIES, 15 CONTACTS, DA, THROUGH HOLE
| Part | Color | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Finish Thickness | Backset Spacing | Backset Spacing | Shell Material, Finish | Connector Type | Mounting Type | Flange Feature | Current Rating (Amps) | Number of Rows [custom] | Connector Style | Contact Finish | Material Flammability Rating | Termination | Shell Size, Connector Layout | Number of Positions | Voltage Rating | Features | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | White | Copper | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Signal | Flash | 7.2 mm | 0.283 in | Nickel Plated Steel | Receptacle Female Sockets | Right Angle Through Hole | Housing/Shell (Unthreaded) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | |||||
 NorComp Inc. | White | Copper | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Signal | Flash | 7.2 mm | 0.283 in | Nickel Plated Steel | Receptacle Female Sockets | Right Angle Through Hole | Mating Side Standard Screws (4-40) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | 500 V | Mounting Brackets | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Receptacle Female Sockets | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Mounting Brackets | Steel | Yellow Chromate Plated | ||||
NorComp Inc. | White | Brass | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Plug Male Pins | Panel Mount Right Angle Through Hole | Housing/Shell (Unthreaded) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Grounding Indents | |||||
 NorComp Inc. | White | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Receptacle Female Sockets | Panel Mount Right Angle Through Hole | Housing/Shell (Unthreaded) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Steel | Yellow Chromate Plated | |||||
 NorComp Inc. | White | Brass | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Nickel Plated Steel | Plug Male Pins | Panel Mount Right Angle Through Hole | Housing/Shell (Unthreaded) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Grounding Indents | ||||
 NorComp Inc. | White | Brass | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Plug Male Pins | Panel Mount Right Angle Through Hole | Mating Side Standard Screws (4-40) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Mounting Brackets | Steel | Yellow Chromate Plated | |||
NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Receptacle Female Sockets | Panel Mount Right Angle Through Hole | Housing/Shell (Unthreaded) | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Steel | Yellow Chromate Plated | |||||
 NorComp Inc. | White | Brass | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Signal | Flash | 7.2 mm | 0.283 in | Nickel Plated Steel | Plug Male Pins | Panel Mount Right Angle Through Hole | Housing/Shell | 5 A | 2 | D-Sub | Gold | UL94 V-0 | Solder | 2 | 15 | Board Lock Grounding Indents Mounting Brackets | 4-40 |
