337-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 22POS 0.156
| Part | Termination Rows | Material - Insulation | Read Out | Number of Positions/Bay/Row | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Mounting Type | Contact Finish | Color | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Termination | Number of Positions | Gender | Flange Feature | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | 22 | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Gold | Green | 0.156 " | 3.96 mm | Cantilever | Wire Wrap | 22 | Female | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | 22 | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Gold | Green | Cantilever | Solder | 22 | Female | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 11 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Dual Edge | Through Hole | Gold | Green | 0.156 " | 3.96 mm | Cantilever | Solder | 22 | Female | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | 22 | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Gold | Green | Cantilever | Wire Wrap | 22 | Female | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 11 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Dual Edge | Right Angle Through Hole | Gold | Green | 0.128 " | 3.25 mm | Cantilever | Wire Wrap | 22 | Female | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | 22 | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Gold | Green | 0.116 " | 2.95 mm | Cantilever | Wire Wrap | 22 | Female | Floating Bobbin Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | Dual | 11 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Dual Edge | Through Hole | Gold | Green | 0.156 " | 3.96 mm | Cantilever | Wire Wrap | 22 | Female | Flush Mount Top Opening Unthreaded | 2 | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | Dual | 11 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Dual Edge | Board Edge Straddle Mount | Gold | Green | Cantilever | Solder Eyelet(s) | 22 | Female | 4-40 Threaded Insert Top Mount Opening | 2 | 2 | Card Extender Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Dual | 11 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Dual Edge | Through Hole | Gold | Green | Cantilever | Solder | 22 | Female | M3 Threaded Insert Top Mount Opening | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Single | 22 | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Copper Alloy | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Gold | Green | Cantilever | Wire Wrap | 22 | Female | 4-40 Threaded Insert Top Mount Opening |
