307-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 32 CONTACTS, PANEL MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Card Type | Number of Positions/Bay/Row | Gender | Color | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Termination | Mounting Type | Contact Type | Contact Finish | Number of Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Termination Rows | Flange Feature | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | Non Specified - Dual Edge | 16 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | |||||||||
 EDAC Inc. | Polyester Thermoplastic | Single | Non Specified - Single Edge | 32 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | Semi Bellows | Gold | -40 C | 105 ░C | 3.96 mm | 0.156 in | 1 | Flush Mount M3 Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | 32 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | 1 | Flush Mount M3 Threaded Insert Top Opening | 64 | |||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | 32 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Semi Bellows | Gold | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 64 | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | Non Specified - Dual Edge | 16 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | Non Specified - Dual Edge | 16 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | Non Specified - Dual Edge | 16 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | ||||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | 32 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Semi Bellows | Tin | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 64 | Card Guides | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | Non Specified - Dual Edge | 16 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Wire Wrap | Right Angle Through Hole | Semi Bellows | Gold | 2 | -40 C | 105 ░C | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | Single | Non Specified - Single Edge | 32 | Female | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | Gold | -40 C | 105 ░C | 3.96 mm | 0.156 in | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | Card Guides |
