140-508 Series
Manufacturer: EDAC Inc.
Beta
⌘K
PIN HEADER, WIRE-TO-BOARD, 2 MM, 1 ROWS, 8 CONTACTS, THROUGH HOLE RIGHT ANGLE, 140 SERIES
| Part | Insulation Color | Contact Finish - Post | Current Rating (Amps) | Contact Length - Post [x] | Contact Length - Post | Insulation Height [z] | Insulation Height [z] | Fastening Type | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Style | Contact Type | Number of Rows | Voltage Rating | Material Flammability Rating | Pitch - Mating | Pitch - Mating | Insulation Material | Number of Positions | Connector Type | Contact Shape | Shrouding | Contact Material | Mounting Type | Number of Positions Loaded | Insulation Height | Insulation Height | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Natural | Tin | 2 A | 0.134 " | 3.4 mm | 0.185 in | 4.7 mm | Detent Lock | Solder | -40 C | 105 ░C | Board to Cable/Wire | Male Pin | 1 | 100 VAC | UL94 V-0 | 0.079 " | 2 mm | Nylon 6/6 Polyamide (PA66) | 8 | Header | Square | Shrouded - 4 Wall | Brass | Right Angle Through Hole | All | |||
 EDAC Inc. | Natural | Tin | 2 A | Detent Lock | Solder | -40 C | 105 ░C | Board to Cable/Wire | Male Pin | 1 | 100 VAC | UL94 V-0 | 0.079 " | 2 mm | Liquid Crystal Polymer (LCP) | 8 | Header | Square | Shrouded - 4 Wall | Brass | Surface Mount | All | 0.217 in | 5.51 mm | Solder Retention | ||||
 EDAC Inc. | Natural | Tin | 2 A | 0.24 in | 6.1 mm | Detent Lock | Kinked Pin Solder | -40 C | 105 ░C | Board to Cable/Wire | Male Pin | 1 | 100 VAC | UL94 V-0 | 0.079 " | 2 mm | Nylon 6/6 Polyamide (PA66) | 8 | Header | Square | Shrouded - 4 Wall | Brass | Through Hole | All | |||||
 EDAC Inc. | Natural | Tin | 2 A | Detent Lock | Kinked Pin Solder | -40 C | 105 ░C | Board to Cable/Wire | Male Pin | 1 | 100 VAC | UL94 V-0 | 0.079 " | 2 mm | Nylon 6/6 Polyamide (PA66) | 8 | Header | Square | Shrouded - 4 Wall | Brass | Right Angle Through Hole | All | 0.197 " | 5 mm |
