MDBRE09 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN D-SUB PLUG 9POS PNL MNT
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Voltage Rating | Dielectric Material | Contact Type | Number of Rows [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness | Connector Type | Ingress Protection | Connector Style | Features | Shell Material, Finish | Number of Positions | Flange Feature | Mounting Type | Contact Finish | Flange Feature | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Black | -40 C | 105 ░C | Copper Alloy | 200 V | Thermoplastic Glass Filled | Signal | 2 | 1 | DE E | UL94 V-0 | 5 A | 30 Áin | 0.76 Ám | Plug Male Pins | IP68 - Dust Tight Waterproof | D-Sub | Board Lock | Nickel Plated Zinc | 9 | Housing/Shell (M3) | Panel Mount | Gold | ||
Amphenol ICC (Commercial Products) | Black | -40 C | 105 ░C | Copper Alloy | 200 V | Thermoplastic Glass Filled | Signal | 2 | 1 | DE E | UL94 V-0 | 5 A | 30 Áin | 0.76 Ám | Receptacle Female Sockets | IP68 - Dust Tight Waterproof | D-Sub | Board Lock | Nickel Plated Zinc | 9 | Housing/Shell (M3) | Panel Mount | Gold | ||
 Amphenol ICC (Commercial Products) | Black | -40 C | 105 ░C | Copper Alloy | 200 V | Thermoplastic Glass Filled | Signal | 2 | 1 | DE E | UL94 V-0 | 5 A | 50 µin | 1.27 µm | Receptacle Female Sockets | IP68 - Dust Tight Waterproof | D-Sub | Board Lock | Nickel Plated Zinc | 9 | Housing/Shell | Panel Mount Through Hole | Gold | 4-40 | Solder |
