Super Sabre Vertical Header, 5 Circuit, Short Solder Tail without Board Lock, Complies with UL1977 Finger Proof Standards, Glow-Wire Capable
Super Sabre Vertical Header, 5 Circuit, Short Solder Tail without Board Lock, Complies with UL1977 Finger Proof Standards, Glow-Wire Capable
Super Sabre Vertical Header, 5 Circuit, Short Solder Tail without Board Lock, Complies with UL1977 Finger Proof Standards, Glow-Wire Capable
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Number of Positions | Termination | Pitch [x] | Pitch [x] | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Features | Mounting Type | Contact Material | Number of Rows | Contact Finish | Voltage Rating | Material - Insulation | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 125 °C | -40 °C | Locking Ramp | 2 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Board Lock Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
 Molex | 125 °C | -40 °C | Locking Ramp | 8 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Board Lock Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
 Molex | 125 °C | -40 °C | Locking Ramp | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black | |
 Molex | 125 °C | -40 °C | Locking Ramp | 6 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
 Molex | 125 °C | -40 °C | Locking Ramp | 4 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Board Lock Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
Molex | 125 °C | -40 °C | Locking Ramp | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black | ||
 Molex | 125 °C | -40 °C | Locking Ramp | 6 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Board Lock Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
 Molex | 125 °C | -40 °C | Locking Ramp | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Finger-Proof | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black | |
 Molex | 125 °C | -40 °C | Locking Ramp | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black | ||
Molex | 125 °C | -40 °C | Locking Ramp | 4 | Solder | 0.295 in | 7.5 mm | Header Male Blades | 2.54 µm | 100 µin | 30 A | Through Hole | Copper | 1 | Silver | 600 V | Liquid Crystal Polymer (LCP) Glass Filled | Black |
