846-088 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 88POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Positions | Card Type | Pitch | Pitch | Color | Gender | Termination | Number of Positions/Bay/Row | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Flange Feature | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Features | Read Out | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Board Edge Straddle Mount | 125 °C | -40 C | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | Dual | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Wire Wrap | 44 | Through Hole | 125 °C | -40 C | Cantilever | Floating Bobbin Top Mount Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Through Hole | 125 °C | -40 C | Cantilever | Flush Mount Top Opening Unthreaded | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Wire Wrap | 44 | Through Hole | 125 °C | -40 C | Cantilever | Flush Mount Top Opening Unthreaded | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Right Angle Through Hole | 125 °C | -40 C | Cantilever | Flush Mount Side Opening Unthreaded | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Right Angle Through Hole | 125 °C | -40 C | Cantilever | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Wire Wrap | 44 | Through Hole | 125 °C | -40 C | Cantilever | 4-40 Threaded Insert Top Mount Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Board Edge Straddle Mount | 125 °C | -40 C | Cantilever | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | Dual | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder | 44 | Through Hole | 125 °C | -40 C | Cantilever | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Copper Alloy | 88 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Green | Female | Solder Eyelet(s) | 44 | Board Edge Straddle Mount | 125 °C | -40 C | Cantilever | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | Dual | 0.128 " | 3.25 mm |
