726-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 6POS 0.125
| Part | Termination Rows | Material - Insulation | Color | Contact Finish | Number of Positions | Contact Material | Pitch | Pitch | Contact Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Number of Rows | Card Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Read Out | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit Wire Wrap | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit Wire Wrap | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit Wire Wrap | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit Wire Wrap | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | Gold | 6 | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Press-Fit | 30 Áin | 0.76 Ám | -40 C | 105 ░C | 6 | 1 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | Through Hole |
