842-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 27POS 0.100
| Part | Termination Rows | Material - Insulation | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Termination | Card Type | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Mounting Type | Pitch | Pitch | Contact Material | Number of Rows | Number of Positions/Bay/Row | Color | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Right Angle Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Single |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Right Angle Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | Single | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Single |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder Eyelet(s) | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Single |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Wire Wrap | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | Flush Mount M3 Threaded Insert Top Opening | Single | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Single |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder Eyelet(s) | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 4-40 Flush Mount Threaded Insert Top Opening | Single | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Wire Wrap | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | Single | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Single |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Solder | Non Specified - Single Edge | Cantilever | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | Copper Alloy | 1 | 27 | Green | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Single |
