179-025 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 25POS R/A SLDR
| Part | Contact Form | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Color | Current Rating (Amps) | Number of Rows [custom] | Contact Finish Thickness | Mounting Type | Shell Material, Finish | Contact Type | Connector Style | Termination | Connector Type | Number of Positions | Contact Finish | Backset Spacing | Backset Spacing | Flange Feature | Flange Feature | Shell Size, Connector Layout | Features | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | Housing/Shell | 4-40 | 3 (DB B) | Shielded | UL94 V-0 |
 NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Shielded | UL94 V-0 | |
NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | Housing/Shell | 4-40 | 3 (DB B) | Board Lock Shielded | UL94 V-0 |
NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Plug Male Pins Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Grounding Indents Shielded | UL94 V-0 | |
NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Plug Male Pins Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Grounding Indents Shielded | UL94 V-0 | |
NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Plug Male Pins Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Grounding Indents Shielded | UL94 V-0 | |
NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Nylon 9T Polyamide (PA9T) | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Nickel Plated Steel | Signal | D-Sub - Stacked | Solder | Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Shielded | UL94 V-0 | |
 NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Polyester Glass Filled | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Signal | D-Sub - Stacked | Solder | Plug Male Pins | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Grounding Indents | UL94 V-0 | ||
 NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Polyester Glass Filled | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Signal | D-Sub - Stacked | Solder | Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock | UL94 V-0 | ||
 NorComp Inc. | Stamped | -55 C | 105 ░C | Brass | Polyester Glass Filled | Black | 5 A | 2 | Flash | Board Edge Right Angle Through Hole | Signal | D-Sub - Stacked | Solder | Plug Male Pins Receptacle Female Sockets | 25 | Gold | 8.08 mm | 0.318 " | 4-40 Mating Side Female Screwlock | 3 (DB B) | Board Lock Grounding Indents | UL94 V-0 |
