845-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Flange Feature | Contact Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Material | Number of Rows [custom] | Card Type | Mounting Type | Contact Finish | Number of Positions/Bay/Row [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Gender | Color | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Through Hole | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Cantilever | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Non Specified - Single Edge | Through Hole | Gold | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 1 | 1 | 0.156 " | 3.96 mm | 36 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Side Mount Opening Unthreaded | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Right Angle Through Hole | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | M3 Threaded Insert Top Mount Opening | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Non Specified - Single Edge | Through Hole | Gold | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 1 | 1 | 36 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Flush Mount M3 Threaded Insert Top Opening | Cantilever | Wire Wrap | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Non Specified - Single Edge | Through Hole | Gold | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 1 | 1 | 36 | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Right Angle Through Hole | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Board Edge Straddle Mount | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 0.128 " | 3.25 mm | Card Extender | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Board Edge Straddle Mount | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 0.128 " | 3.25 mm | Card Extender | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | Flush Mount Side Opening Unthreaded | Cantilever | Wire Wrap | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Through Hole | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Dual | 4-40 Threaded Insert Top Mount Opening | Cantilever | Solder | 0.25 Ám | 10 Áin | 36 | Copper Alloy | 2 | Non Specified - Dual Edge | Right Angle Through Hole | Gold | 18 | 125 °C | -40 C | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Green |
