PCA Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
SWITCHING POWER SUPPLIES 636W 12V 53A W/ ALARM
| Part | Standard Number | Voltage - Output 1 | Voltage - Isolation | Efficiency | Power (Watts) | Applications | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output 1 | Number of Outputs | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Operating Temperature [Min] | Operating Temperature [Max] | Features | Type | Mounting Type | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 12 V | 4000 V | 92 % | 636 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 264 VAC 370 VDC | 85 VAC 88 VDC | 53 A | 1 | 3.5 " | 152 mm | 5.98 in | 1.61 " | 89 mm | 41 mm | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount | ||
Cosel USA, Inc. | 60601-1; 62368-1 | 48 V | 4000 V | 93 % | 624 W | ITE (Commercial) Medical | CE cURus DEMKO UKCA | 264 VAC 370 VDC | 85 VAC 88 VDC | 13 A | 1 | 3.5 " | 152 mm | 5.98 in | 1.61 " | 89 mm | 41 mm | -20 ░C | 70 °C | DC Input Capable PFC PMBus™ Universal Input | Enclosed | Chassis Mount | ||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 32 V | 4000 V | 93 % | 1056 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 33 A | 1 | 4.02 in | 178 mm | 7.01 in | 1.61 " | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Conformal Coated Enclosed | Chassis Mount | 102 mm | 41 mm | ||||
 Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 32 V | 4000 V | 93 % | 640 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 264 VAC 370 VDC | 85 VAC 88 VDC | 20 A | 1 | 3.5 " | 152 mm | 5.98 in | 1.61 " | 89 mm | 41 mm | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount | ||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 24 V | 4000 V | 93 % | 648 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 264 VAC 370 VDC | 85 VAC 88 VDC | 27 A | 1 | 3.5 " | 152 mm | 5.98 in | 1.61 " | 89 mm | 41 mm | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Conformal Coated Enclosed | Chassis Mount | ||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 12 V | 4000 V | 92 % | 1056 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 88 A | 1 | 4.02 in | 178 mm | 7.01 in | 1.61 " | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount | 102 mm | 41 mm | ||||
 Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 12 V | 4000 V | 92 % | 1056 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 88 A | 1 | 4.02 in | 178 mm | 7.01 in | 1.61 " | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount | 102 mm | 41 mm | ||||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 15 V | 4000 V | 92 % | 1050 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 70 A | 1 | 4.02 in | 178 mm | 7.01 in | 1.61 " | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount | 102 mm | 41 mm | ||||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 5 V | 4000 V | 91 % | 1 kW | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 200 A | 1 | 4.02 in | 178 mm | 7.01 in | 1.61 " | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Conformal Coated Enclosed | Chassis Mount | 102 mm | 41 mm | ||||
Cosel USA, Inc. | 60601-1 60950-1 62368-1 | 48 V | 4000 V | 91 % | 336 W | ITE (Commercial) Medical | CE CSA cURus D-Mark UL | 264 VAC 370 VDC | 85 VAC 88 VDC | 7 A | 1 | 3.5 " | 152 mm | 5.98 in | 1.61 " | 89 mm | 41 mm | -20 ░C | 70 °C | Adjustable Output PFC Remote On/Off Remote Sense Universal Input | Enclosed | Chassis Mount |
