VC02 Series

Catalog

TERM BLOCK HDR 2POS 90DEG 7.62MM

Part	Mounting Type	Material Flammability Rating	Housing Material	Number of Levels	Number of Positions	Contact Mating Finish	Type	Termination Style	Insulation Height	Insulation Height	Header Orientation	Voltage - UL	Pitch [x]	Pitch [x]	Positions Per Level	Contact Material	Current - UL	Operating Temperature [Min]	Operating Temperature [Max]	Contact Tail Length	Contact Tail Length	Color	Features	Header Orientation
Amphenol Anytek VC0200500000G	Through Hole	UL94 V-0	Thermoplastic Resin	1	2	Tin	Header Male Pins Shrouded (4 Side)	Solder	14.3 mm	0.563 in	90° Right Angle	300 V	0.3 in	7.62 mm	2	Copper Alloy	32 A	-40 °C	115 °C	5 mm	0.197 in	Green
Amphenol Anytek VC0202510000G		UL94 V-0	Thermoplastic	1	2	Tin	Blade Pins Header Shrouded (4 Side)	Quick Connect - 0.187" (4.7mm)	29.3 mm	1.154 in	Vertical	300 V	0.3 in	7.62 mm	2	Copper		-40 °C	115 °C	8.31 mm	0.327 in	Green	Mounting Flange
Amphenol Anytek VC02015A0000G	Through Hole	UL94 V-0	Thermoplastic	1	2	Tin	Blade Pins Header Shrouded (4 Side)	Solder	29.3 mm	1.154 in	Vertical	300 V	0.3 in	7.62 mm	2	Copper	41 A	-40 °C	115 °C	5 mm	0.197 in	Green	Mounting Flange
Amphenol Anytek VC0201500000G	Through Hole	UL94 V-0	Thermoplastic Resin	1	2	Tin	Blade Pins Header Shrouded (4 Side)	Solder	14.3 mm	0.563 in	90° Right Angle	300 V	0.3 in	7.62 mm	2	Copper Alloy	32 A	-40 °C	115 °C	5 mm	0.197 in	Green	Mating Flange
Amphenol Anytek VC0200510000G	Through Hole	UL94 V-0	Thermoplastic Resin	1	2	Tin	Header Male Pins Shrouded (4 Side)	Solder	29 mm	1.142 in	Vertical	300 V	0.3 in	7.62 mm	2	Copper Alloy	32 A	-40 °C	115 °C	5 mm	0.197 in	Green
Amphenol Anytek VC02035B0000G	Through Hole			1	2		Blade Pins Header Shrouded (4 Side)	Solder			90° Right Angle	300 V	0.3 in	7.62 mm	2		32 A					Green
Amphenol Anytek VC02035C0000G	Through Hole			1	2		Blade Pins Header Shrouded (4 Side)	Solder			Right Angle Under Board	300 V	0.3 in	7.62 mm	2		32 A					Green		90 °
Amphenol Anytek VC0201510000G	Through Hole	UL94 V-0	Thermoplastic Resin	1	2	Tin	Blade Pins Header Shrouded (4 Side)	Solder	29 mm	1.142 in	Vertical	300 V	0.3 in	7.62 mm	2	Copper Alloy	32 A	-40 °C	115 °C	5 mm	0.197 in	Green	Mating Flange
Amphenol Anytek VC02015C0000G	Through Hole	UL94 V-0	Thermoplastic	1	2	Tin	Blade Pins Header Shrouded (4 Side)	Solder	14.3 mm	0.563 in	Right Angle Under Board	300 V	0.3 in	7.62 mm	2	Copper	41 A	-40 °C	115 °C	3.9 mm	0.154 "	Green	Mounting Flange	90 °
