FKICS Series
Pluggable Terminal Blocks 7 Pos 5mm Invert Plug 24-12AWG Spring
Manufacturer: Phoenix Contact
Catalog
Pluggable Terminal Blocks 7 Pos 5mm Invert Plug 24-12AWG Spring
Beta
⌘K
Pluggable Terminal Blocks 7 Pos 5mm Invert Plug 24-12AWG Spring
Pluggable Terminal Blocks 7 Pos 5mm Invert Plug 24-12AWG Spring
Pluggable Terminal Blocks 7 Pos 5mm Invert Plug 24-12AWG Spring
| Part | Material Flammability Rating | Housing Material | Wire Strip Length | Insulation Height [custom] | Insulation Height [custom] | Wire Gauge or Range - mm˛ [Max] | Wire Gauge or Range - mm˛ [Min] | Positions Per Level | Plug Wire Entry | Current - UL | Pitch | Pitch | Number of Levels | Voltage - UL | Wire Gauge or Range - mm² [Max] | Wire Gauge or Range - mm² [Min] | Voltage - IEC | Current - IEC | Termination Style | Features | Number of Positions | Contact Mating Finish | Mounting Type | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Color | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | UL94 V-0 | Polyamide (PA) Nylon | 10 mm | 0.591 in | 15 mm | 2.5 mm˛ | 0.2 mm˛ | 15 | 180 ° | 10 A | 5.08 mm | 0.2 in | 1 | 300 V | 2.5 mm² | 0.2 mm² | 630 V | 12 A | Push-In Spring Screwless - Leg Spring | Mating Flange | 15 | Tin | Free Hanging (In-Line) | 12 AWG | 26 AWG | Green | |
Phoenix Contact | UL94 V-0 | Polyamide (PA) Nylon | 10 mm | 0.591 in | 15 mm | 180 ° | 10 A | 5 mm | 0.197 in | 1 | 300 V | 2.5 mm² | 0.2 mm² | 630 V | 12 A | Push-In Spring Screwless - Leg Spring | Mating Flange | 7 | Tin | Free Hanging (In-Line) | 12 AWG | 26 AWG | Green | 7 |
