29804 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE DPDT 6A 24V
| Part | Coil Resistance | Contact Rating (Current) | Contact Material | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Operate Time | Termination Style | Contact Form | Mounting Type | Coil Current | Coil Type | Approval Agency | Release Time | Relay Type | Switching Voltage | Features | Coil Voltage | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 2.4 kOhms | 6 A | Silver Nickel (AgNi) | 24 VDC | 70 °C | -40 C | 8 ms | Screw Terminal | DPDT (2 Form C) | DIN Rail | 10 mA | Non Latching | CE UKCA | 10 ms | General Purpose | 250 VAC 250 VDC | Lighted Indicator Socket Included | ||
 Phoenix Contact | 26.6 kOhms | 6 A | Silver Tin Oxide (AgSnO) | 55 °C | -40 C | 7 ms | Screw Terminal | SPDT (1 Form C) | DIN Rail | 10 mA | Non Latching | CE UKCA | 20 ms | General Purpose | 250 VAC 250 VDC | Lighted Indicator Socket Included | 230 VDC | 230 VAC |
