307-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 16POS 0.156
| Part | Termination Rows | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Positions/Bay/Row | Color | Number of Positions | Mounting Type | Number of Rows [custom] | Read Out | Features | Contact Material | Contact Type | Card Type | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Termination | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | 8 | Green | 16 | Right Angle Through Hole | 2 | Dual | Card Guides | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder | Gold | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | 8 | Green | 16 | Surface Mount | 2 | Dual | Card Guides | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder Eyelet(s) | Gold | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | Female | 8 | Green | 8 | Through Hole | Single | Copper Alloy | Semi Bellows | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder | Tin | 3.25 mm | 0.128 " | 1 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 8 | Green | 8 | Right Angle Through Hole | Single | Copper Alloy | Semi Bellows | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder | Gold | 1 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | Female | 8 | Green | 8 | Through Hole | Single | Copper Alloy | Semi Bellows | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Wire Wrap | Gold | 3.25 mm | 0.128 " | 1 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Floating Bobbin Flush Mount | 0.25 Ám | 10 Áin | Female | 8 | Green | 16 | Surface Mount | 2 | Dual | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder Eyelet(s) | Gold | 2.95 mm | 0.116 " | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | 8 | Green | 16 | Surface Mount | 2 | Dual | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder Eyelet(s) | Gold | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | Female | 8 | Green | 16 | Surface Mount | 2 | Dual | Copper Alloy | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder Eyelet(s) | Gold | 3.25 mm | 0.128 " | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Floating Bobbin Flush Mount | Female | 8 | Green | 8 | Through Hole | Single | Copper Alloy | Semi Bellows | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Wire Wrap | Tin | 2.95 mm | 0.116 " | 1 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Female | 8 | Green | 8 | Through Hole | Single | Card Guides | Copper Alloy | Semi Bellows | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Wire Wrap | Tin | 1 |
