E3Z-D81 Series

Catalog

SENSOR REFLECTIVE 100MM PNP

Part	Ingress Protection	Light Source	Response Time	Output Configuration	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Min]	Connection Method	Voltage - Supply [Min]	Voltage - Supply [Max]	Sensing Method	Operating Temperature [Max]	Operating Temperature [Min]
Omron Automation and Safety E3Z-D81K-M3J 0.3M	IEC IP67 IP67 IEC	Infrared (860nm)	1 ms	PNP - Dark-ON/Light-ON - Selectable	3.937 in	0.197 in	100 mm	5 mm	Cable	12 VDC	24 V	Diffuse Reflective	55 °C	-25 °C
Omron Automation and Safety E3Z-D81 0.5M	IEC IP67 IP67 IEC	Infrared (860nm)	1 ms	PNP - Dark-ON/Light-ON - Selectable	3.937 in	0.197 in	100 mm	5 mm	Cable	12 VDC	24 V	Diffuse Reflective	55 °C	-25 °C
Omron Automation and Safety E3Z-D81 5M	IEC IP67 IP67 IEC	Infrared (860nm)	1 ms	PNP - Dark-ON/Light-ON - Selectable	3.937 in	0.197 in	100 mm	5 mm	Cable	12 VDC	24 V	Diffuse Reflective	55 °C	-25 °C
Omron Automation and Safety E3Z-D81-M1J 0.3M	IEC IP67 IP67 IEC	Infrared (860nm)	1 ms	PNP - Dark-ON/Light-ON - Selectable	3.937 in	0.197 in	100 mm	5 mm	Cable	12 VDC	24 V	Diffuse Reflective	55 °C	-25 °C
