CLP Series
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
Manufacturer: OmniOn Power™
Catalog
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
Beta
⌘K
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
| Part | Voltage - Output 1 | Type | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Features | Number of Outputs | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension | Efficiency | Mounting Type | Current - Output 1 | Voltage - Isolation | Power (Watts) | Standard Number | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Voltage - Input (Max) [Max] | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OmniOn Power™ | 24 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | CB CE cUL UL | 265 VAC | 90 VAC | Adjustable Output Remote On/Off Remote Sense Standby Output Universal Input | 1 | 3 " | 1.38 in | 5 " | 35.1 mm 76.2 mm 127 mm | 92 % | Chassis Mount | 18.8 A | 3000 V | 451 W | |||||||
 OmniOn Power™ | 24 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | CB CE CSA cUL TUV UL | 264 VAC | 90 VAC | Adjustable Output PFC Universal Input | 1 | 2 in | 1.3 in | 4 " | Chassis Mount | 8.33 A | 3000 V | 200 Watts | 60950-1 | 33.1 mm | 101.6 mm | 50.8 mm | |||||
 OmniOn Power™ | 24 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | CB CE CSA cUL TUV UL | 264 VAC | 90 VAC | Adjustable Output PFC Universal Input | 1 | 2 in | 1.3 in | 4 " | Chassis Mount | 8.33 A | 3000 V | 200 Watts | 60950-1 | 33.1 mm | 101.6 mm | 50.8 mm | |||||
 OmniOn Power™ | 12 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | CB CE cUL TUV UL | 1 | 2 in | 1.4 " | 4 " | 93 % | Chassis Mount | 1000 V | 200 Watts | 35.6 mm | 101.6 mm | 50.8 mm | 75 V | 16.7 A | 36 V | ||||||
 OmniOn Power™ | 54 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | CB CE cUL UL | 265 VAC | 90 VAC | Adjustable Output Remote On/Off Remote Sense Standby Output Universal Input | 1 | 2 in | 1.4 " | 4 " | 92 % | Chassis Mount | 3.7 A | 3000 V | 200 Watts | 35.6 mm | 101.6 mm | 50.8 mm | |||||
OmniOn Power™ | 12 V | Open Frame | -40 °C | 85 °C | ITE (Commercial) | 264 VAC | 90 VAC | Adjustable Output PFC Remote On/Off Remote Sense Standby Output Universal Input | 1 | 2 in | 1.3 in | 4 " | 92.7 % | Chassis Mount | 12.5 A | 3000 V | 150 W | 60950-1 | 33.1 mm | 101.6 mm | 50.8 mm |
