MGDBK04 Series

Catalog

DC DC CONVERTER

Part	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Output 2	Package / Case	Mounting Type	Voltage - Input (Min) [Min]	Efficiency	Type	Number of Outputs	Current - Output (Max) [Max]	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Voltage - Isolation	Voltage - Input (Max) [Max]	Applications
Gaia Converter MGDBK04QE	12 V	1.3 in	0.31 "	7.8 mm	33 mm	0.79 in	20 mm	-12 V	24-DIP Module 8 Leads	Through Hole	36 V	80 %	Isolated Module	2	165 mA	165 mA	-40 C	95 °C	4 W	1.5 kV	140 V	ITE (Commercial)
