ISO7810 Series

Highest isolation rating, single-channel, reinforced digital isolator

Catalog

Highest isolation rating, single-channel, reinforced digital isolator

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Voltage - Isolation	Type	Package / Case [x]	Package / Case	Package / Case [y]	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Pulse Width Distortion (Max)	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Number of Channels	Data Rate	Technology	Inputs - Side 1/Side 2 [custom]	Mounting Type	Common Mode Transient Immunity (Min) [Min]	Channel Type	Propagation Delay tpLH / tpHL (Max) [Max] [custom]	Propagation Delay tpLH / tpHL (Max) [Max] [custom]
Texas Instruments ISO7810DW	5.5 V	2.25 V	5700 Vrms	General Purpose	0.295 in	16-SOIC	7.5 mm	-55 °C	125 °C	16-SOIC	4.6 ns	2.4 ns	2.4 ns	1	100 Mbps	Capacitive Coupling	1	Surface Mount	100 V/ns	Unidirectional	16 ns	16 ns
Texas Instruments ISO7810DWWR	5.5 V	2.25 V	5700 Vrms	General Purpose		16-SOIC		-55 °C	125 °C	16-SOIC	4.6 ns	2.4 ns	2.4 ns	1	100 Mbps	Capacitive Coupling	1	Surface Mount	100 V/ns	Unidirectional	16 ns	16 ns
Texas Instruments ISO7810FDWW	5.5 V	2.25 V	5700 Vrms	General Purpose		16-SOIC		-55 °C	125 °C	16-SOIC	4.6 ns	2.4 ns	2.4 ns	1	100 Mbps	Capacitive Coupling	1	Surface Mount	100 V/ns	Unidirectional	16 ns	16 ns
Texas Instruments ISO7810FDWWR	5.5 V	2.25 V	5700 Vrms	General Purpose		16-SOIC		-55 °C	125 °C	16-SOIC	4.6 ns	2.4 ns	2.4 ns	1	100 Mbps	Capacitive Coupling	1	Surface Mount	100 V/ns	Unidirectional	16 ns	16 ns

Catalog

Highest isolation rating, single-channel, reinforced digital isolator

Key Features

• Signaling Rate: Up to 100 MbpsWide Supply Range: 2.25 V to 5.5 V2.25 V to 5.5 V Level TranslationWide Temperature Range: –55°C to 125°CLow Power Consumption, Typical 1.8 mA at1 MbpsLow Propagation Delay: 10.7 ns Typical(5 V Supplies)Industry leading CMTI (Min): ±100 kV/µsRobust Electromagnetic Compatibility (EMC)System-Level ESD, EFT, and Surge ImmunityLow EmissionsIsolation Barrier Life: > 40 YearsSOIC-16 Wide Body (DW) and Extra-Wide Body(DWW) Package OptionsSafety-Related Certifications:8000 VPKReinforced Isolation per DIN V VDEV 0884-10 (VDE V 0884-10):2006-125.7 kVRMSIsolation for 1 minute per UL 1577CSA Component Acceptance Notice 5A, IEC60950-1 and IEC 60601-1 End EquipmentStandardsCQC Certification per GB4943.1-2011TUV Certification per EN 61010-1 and EN60950-1All DW Package Certifications Complete;DWW Package Certifications Complete perUL, VDE, and TUV and Planned for CSA andCQCSignaling Rate: Up to 100 MbpsWide Supply Range: 2.25 V to 5.5 V2.25 V to 5.5 V Level TranslationWide Temperature Range: –55°C to 125°CLow Power Consumption, Typical 1.8 mA at1 MbpsLow Propagation Delay: 10.7 ns Typical(5 V Supplies)Industry leading CMTI (Min): ±100 kV/µsRobust Electromagnetic Compatibility (EMC)System-Level ESD, EFT, and Surge ImmunityLow EmissionsIsolation Barrier Life: > 40 YearsSOIC-16 Wide Body (DW) and Extra-Wide Body(DWW) Package OptionsSafety-Related Certifications:8000 VPKReinforced Isolation per DIN V VDEV 0884-10 (VDE V 0884-10):2006-125.7 kVRMSIsolation for 1 minute per UL 1577CSA Component Acceptance Notice 5A, IEC60950-1 and IEC 60601-1 End EquipmentStandardsCQC Certification per GB4943.1-2011TUV Certification per EN 61010-1 and EN60950-1All DW Package Certifications Complete;DWW Package Certifications Complete perUL, VDE, and TUV and Planned for CSA andCQC

Description

The ISO7810x device is a high-performance, single-channel digital isolator with 8000 VPKisolation voltage. This device has reinforced isolation certifications according to VDE, CSA, CQC, and TUV. The isolator provides high electromagnetic immunity and low emissions at low power consumption, while isolating CMOS or LVCMOS digital I/Os. The isolation channel has a logic input and output buffer separated by silicon dioxide (SiO2) insulation barrier. If the input power or signal is lost, the default output is for the ISO7810 and for the ISO7810F device. See theDevice Functional Modessection for further details. Used in conjunction with isolated power supplies, this device helps prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. Through innovative chip design and layout techniques, electromagnetic compatibility of the ISO7810x device has been significantly enhanced to ease system-level ESD, EFT, surge, and emissions compliance. The ISO7810x device is available in 16-pin SOIC wide-body (DW) and extra-wide body (DWW) packages.The DWW package option comes with enable pin which can be used to put the output in high impedance state for multi-master driving applications and to reduce power consumption. The ISO7810x device is a high-performance, single-channel digital isolator with 8000 VPKisolation voltage. This device has reinforced isolation certifications according to VDE, CSA, CQC, and TUV. The isolator provides high electromagnetic immunity and low emissions at low power consumption, while isolating CMOS or LVCMOS digital I/Os. The isolation channel has a logic input and output buffer separated by silicon dioxide (SiO2) insulation barrier. If the input power or signal is lost, the default output is for the ISO7810 and for the ISO7810F device. See theDevice Functional Modessection for further details. Used in conjunction with isolated power supplies, this device helps prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. Through innovative chip design and layout techniques, electromagnetic compatibility of the ISO7810x device has been significantly enhanced to ease system-level ESD, EFT, surge, and emissions compliance. The ISO7810x device is available in 16-pin SOIC wide-body (DW) and extra-wide body (DWW) packages.The DWW package option comes with enable pin which can be used to put the output in high impedance state for multi-master driving applications and to reduce power consumption.
