337-066 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 66POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Contact Material | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Card Type | Termination | Gender | Color | Mounting Type | Contact Type | Contact Finish | Read Out | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 0.156 " | 3.96 mm | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Wire Wrap | Female | Green | Through Hole | Cantilever | Gold | Dual | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Through Hole | Cantilever | Gold | Dual | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 0.128 " | 3.25 mm | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Through Hole | Cantilever | Gold | Dual | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Wire Wrap | Female | Green | Right Angle Through Hole | Cantilever | Gold | Dual | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Wire Wrap | Female | Green | Through Hole | Cantilever | Gold | Dual | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Board Edge Straddle Mount | Cantilever | Gold | Dual | 4-40 Threaded Insert Top Mount Opening | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Through Hole | Cantilever | Gold | Dual | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 0.116 " | 2.95 mm | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Board Edge Straddle Mount | Cantilever | Gold | Dual | Floating Bobbin Top Mount Opening | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Wire Wrap | Female | Green | Right Angle Through Hole | Cantilever | Gold | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Copper Alloy | 66 | 0.156 " | 3.96 mm | 2 | 33 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Solder | Female | Green | Through Hole | Cantilever | Gold | Dual | Flush Mount Top Opening Unthreaded |
