V7-1A1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION SPDT 5A 125V
| Part | Release Force | Voltage Rating - AC | Operating Temperature [Max] | Operating Temperature [Min] | Circuit | Actuator Type | Mounting Type | Operating Position | Operating Position | Pretravel | Pretravel | Mechanical Life | Switch Function | Current Rating (Amps) | Overtravel [custom] | Overtravel [custom] | Differential Travel [x] | Differential Travel [x] | Electrical Life | Termination Style | Operating Force | Differential Travel | Differential Travel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 25 gf | 125 V | 85 °C | -40 C | SPDT | Round (Pin Plunger) | Right Angle Through Hole | 14.7 mm | 0.579 in | 1.2 mm | 0.047 in | 10000000 Cycles | On-Mom | 5 A | 1.27 mm | 0.05 " | 0.01 in | 0.25 mm | 100000 Cycles | PC Pin | 150 gf | ||
 Honeywell Sensing and Productivity Solutions | 3 gf | 125 V | 85 °C | -40 C | SPDT | Lever Straight | Chassis Mount | 15.3 mm | 0.602 in | 7.6 mm | 0.3 in | 10000000 Cycles | On-Mom | 5 A | 3.7 mm | 0.146 " | 100000 Cycles | Quick Connect | 38 gf | 1.8 mm | 0.07 in | ||
Honeywell Sensing and Productivity Solutions |
