98481 Series

Catalog

CONN HEADER VERT 25POS 2.54MM

Part	Termination	Shrouding	Pitch - Mating	Pitch - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Color	Style	Contact Material	Contact Shape	Contact Length - Mating	Contact Length - Mating	Material Flammability Rating	Number of Rows	Contact Finish - Mating	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Fastening Type	Mounting Type	Current Rating (Amps)	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Contact Type	Number of Positions Loaded	Insulation Height	Insulation Height	Insulation Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions
Amphenol ICC (FCI) 98481-325LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin
Amphenol ICC (FCI) 98481-328LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	28
Amphenol ICC (FCI) 98481-427LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1		125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	78.7 µin	2 µm	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	27
Amphenol ICC (FCI) 98481-331LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	31
Amphenol ICC (FCI) 98481-329LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	29
Amphenol ICC (FCI) 98481-330LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	30
Amphenol ICC (FCI) 98481-326LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	26
Amphenol ICC (FCI) 98481-336LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	36
Amphenol ICC (FCI) 98481-323LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	23
Amphenol ICC (FCI) 98481-319LF	Solder	Shrouded - 2 Wall	0.1 in	2.54 mm	0.134 in	3.4 mm	Blue	Board to Cable/Wire	Phosphor Bronze	Square	0.197 in	5 mm	UL94 V-0	1	Gold GXT™	125 °C	-40 °C	Header	Friction Lock	Through Hole	3 A	30 Áin	0.76 Ám	Tin	Male Pin	All	9.35 mm	0.368 in	Polyester Glass Filled	2 çm	78.7 çin	19
