H2L8 Series
Manufacturer: Panduit Corp
Beta
⌘K
CONN TERM RECT LUG 1-4 AWG #1/2
| Part | Width - Outer Edges [y] | Width - Outer Edges [y] | Terminal Type | Contact Material | Termination | Features | Features [custom] | Stud/Tab Size | Terminal Style | Mounting Type | Length - Overall [x] | Length - Overall [x] | Insulation | Wire Gauge [Min] | Wire Gauge [Max] | Tab Thickness | Tab Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | 1.38 in | 35.05 mm | Grounding Lug | Copper Alloy | Screw | With Screw | 2 | 1/2 Stud | Two Stud Holes | Free Hanging (In-Line) | 100.08 mm | 3.94 in | Non-Insulated | 1 AWG | 4 AWG | 5.59 mm | 0.22 in |
