MSTBA Series
Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
Manufacturer: Phoenix Contact
Catalog
Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
Beta
⌘K
Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
| Part | Material Flammability Rating | Housing Material | Contact Tail Length | Contact Tail Length | Insulation Height | Insulation Height | Voltage - UL | Positions Per Level | Termination Style | Mounting Type | Number of Positions | Voltage - IEC | Color | Number of Levels | Current - IEC | Header Orientation | Type | Pitch | Pitch | Contact Mating Finish | Features | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | UL94 V-0 | Polyamide (PA) Nylon | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 12 | Solder | Through Hole | 12 | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | Tin | ||
 Phoenix Contact | UL94 V-0 | Polybutylene Terephthalate (PBT) | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 3 | Solder | Through Hole | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | Tin | Locking Ramp | ||
 Phoenix Contact | UL94 V-0 | Polybutylene Terephthalate (PBT) | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 5 | Solder | Through Hole | 5 | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | Gold | ||
 Phoenix Contact | UL94 V-0 | Polybutylene Terephthalate (PBT) | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 2 | Solder | Through Hole | 2 | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | Tin | Locking Ramp | |
 Phoenix Contact | 300 V | 15 | Solder | Through Hole | 15 | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | Tin | Locking Ramp | |||||||
 Phoenix Contact | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 8 | Solder | Through Hole | 8 | 250 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | Gold | ||||
 Phoenix Contact | UL94 V-0 | Polybutylene Terephthalate (PBT) | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 5 | Solder | Through Hole | 5 | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | Tin | Locking Ramp | |
Phoenix Contact | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | Solder | Through Hole | 7 | 250 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | Tin | 7 | |||||
 Phoenix Contact | UL94 V-0 | Polyamide (PA) Nylon | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 300 V | 17 | Solder | Through Hole | 400 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | Tin | |||
 Phoenix Contact | 0.138 in | 3.5 mm | 8.61 mm | 0.339 " | 11 | Solder | Through Hole | 11 | 250 V | Green | 1 | 12 A | 90° Right Angle | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | Gold |
