333.1 Series

Catalog

HANDLE ALUMINUM MTG CTR 7.78"

Part	Material	Length - Center to Center [x]	Length - Center to Center [x]	Thread/Screw/Hole Size	Type	Height [z]	Height [z]	Mounting Type	Length - Center to Center	Length - Center to Center	Height	Height
J.W. Winco 333.1-28-8-A-EL	Aluminum	7.78 in	197.61 mm	M8	Instrumentation	66.04 mm	66.04 mm	Screw Holes Back
J.W. Winco 333.1-30-1000-A-EL	Aluminum			M8	Instrumentation	68.07 mm	2.68 in	Screw Holes Back	1000 mm	39.37 in
J.W. Winco 333.1-30-500-A-SW	Aluminum			M8	Instrumentation	68.07 mm	2.68 in	Screw Holes Back	500.13 mm	19.69 in
J.W. Winco 333.1-30-400-A-EL	Aluminum	15.75 in	400.05 mm	M8	Instrumentation	68.07 mm	2.68 in	Screw Holes Back
J.W. Winco 333.1-20-12-A-EL	Aluminum	11.81 in	299.97 mm	M6	Instrumentation			Screw Holes Back			54.1 mm	2.13 in
J.W. Winco 333.1-1.10-12.00-A-ES	Aluminum	11.81 in	299.97 mm	M8	Instrumentation	66.04 mm	66.04 mm	Screw Holes Back
J.W. Winco 333.1-30-1000-A-SW	Aluminum			M8	Instrumentation	68.07 mm	2.68 in	Screw Holes Back	1000 mm	39.37 in
J.W. Winco 333.1-28-350-B-SW	Aluminum	13.78 in	350.01 mm	M8	Instrumentation	66.04 mm	66.04 mm	Screw Holes Back
J.W. Winco 333.1-20-350-A-SW	Aluminum	13.78 in	350.01 mm	M6	Instrumentation			Screw Holes Back			54.1 mm	2.13 in
J.W. Winco 333.1-28-24-A-ES	Aluminum			M8	Instrumentation	66.04 mm	66.04 mm	Screw Holes Back	599.95 mm	23.62 in
