68799 Series

Catalog

CONN HEADER VERT 72POS 2.54MM

Part	Contact Type	Contact Shape	Contact Length - Mating [x]	Contact Length - Mating	Termination	Fastening Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions	Connector Type	Contact Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Number of Rows	Mounting Type	Insulation Color	Insulation Height	Insulation Height	Overall Contact Length	Overall Contact Length	Shrouding	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Number of Positions Loaded	Contact Finish - Mating
Amphenol ICC (FCI) 68799-472	Male Pin	Square	0.23 in	5.84 mm	Solder	Push-Pull	2.54 mm	0.1 in	72	Header	Phosphor Bronze	2.54 çm	100 çin	15.11 mm	0.595 in	2	Through Hole	Black	0.1 in	2.54 mm	0.925 in	23.5 mm	Unshrouded	0.1 in	2.54 mm	UL94 V-0	All
Amphenol ICC (FCI) 68799-272HLF	Male Pin	Square	0.23 in	5.84 mm	Solder	Push-Pull	2.54 mm	0.1 in	72	Header	Phosphor Bronze	0.38 µm	15 µin	15.11 mm	0.595 in	2	Through Hole	Black	0.1 in	2.54 mm	0.925 in	23.5 mm	Unshrouded	0.1 in	2.54 mm	UL94 V-0	All	Gold or Gold GXT™
Amphenol ICC (FCI) 68799-160HLF	Male Pin	Square	0.23 in	5.84 mm	Solder	Push-Pull	2.54 mm	0.1 in	60	Header	Phosphor Bronze	0.76 Ám	30 Áin	15.11 mm	0.595 in	2	Through Hole	Black	0.1 in	2.54 mm	0.925 in	23.5 mm	Unshrouded	0.1 in	2.54 mm	UL94 V-0	All	Gold or Gold GXT™
