845-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Gender | Card Type | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Contact Finish | Contact Type | Mounting Type | Read Out | Pitch | Pitch | Number of Positions/Bay/Row | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Color | Features | Flange Feature | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Right Angle Through Hole | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Board Edge Straddle Mount | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Card Extender | Floating Bobbin Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Through Hole | Single | 0.1 " | 2.54 mm | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Side Mount Opening Unthreaded | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Through Hole | Single | 0.1 " | 2.54 mm | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Flush Mount Side Opening Unthreaded | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Through Hole | Single | 0.1 " | 2.54 mm | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Board Edge Straddle Mount | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Card Extender | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 125 °C | -40 C | 14 | Gold | Cantilever | Through Hole | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Board Edge Straddle Mount | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Card Extender | Floating Bobbin Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Right Angle Through Hole | Dual | 0.1 " | 2.54 mm | 7 | 2 | 0.25 Ám | 10 Áin | Copper Alloy | Green | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 14 | Gold | Cantilever | Through Hole | Single | 0.1 " | 2.54 mm | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | M3 Threaded Insert Top Mount Opening | 1 | 1 |
