GDLX Series
Manufacturer: Kycon, Inc.
Beta
⌘K
MODULAR CONNECTORS / ETHERNET CONNECTORS SMT M/JK RT< 8P8C SHLD BLK KEY
| Part | Contact Finish Thickness | Housing Material | Operating Temperature [Max] | Operating Temperature [Min] | Termination | LED Color | Number of Ports | Shielding | Contact Finish | Contact Material | Tab Direction | Connector Type | Mounting Type | Number of Positions/Contacts | Number of Rows | Features | Orientation | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kycon, Inc. | Flash | Thermoplastic | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Shielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount Right Angle Through Hole | 8p8c (RJ45 Ethernet) | 1 | Board Lock Keyed Panel Stops | 90 ° | ||||
 Kycon, Inc. | Polybutylene Terephthalate (PBT) | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Shielded | Gold | Phosphor Bronze | Down | Jack | Through Hole | 8p8c (RJ45 Ethernet) | 1 | Board Lock Keyed | 90 ° | 50 µin | 1.27 µm | |||
 Kycon, Inc. | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Through Hole | 8p8c (RJ45 Ethernet) | 1 | Board Lock | 90 ° | ||||||||
Kycon, Inc. | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount | 1 | Board Lock | 90 ° | 6 | 6 | |||||||
 Kycon, Inc. | Solder | Does Not Contain LED | 1 | Shielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount Right Angle Through Hole | 8p8c (RJ45 Ethernet) | 1 | Board Lock Panel Stops | 90 ° | ||||||||
 Kycon, Inc. | Polybutylene Terephthalate (PBT) | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Through Hole | 1 | Board Lock | 90 ° | 50 µin | 1.27 µm | 4 | 6 | ||
Kycon, Inc. | Flash | Polybutylene Terephthalate (PBT) | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Through Hole | 1 | Board Lock | 90 ° | 4 | 6 | |||
 Kycon, Inc. | Flash | Thermoplastic | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Shielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount Right Angle Through Hole | 8p8c (RJ45 Ethernet) | 1 | Board Lock Panel Stops | 90 ° | ||||
Kycon, Inc. | Flash | Thermoplastic | 85 °C | -40 C | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount | 1 | Board Lock | 90 ° | 4 | 6 | |||
 Kycon, Inc. | Solder | Does Not Contain LED | 1 | Unshielded | Gold | Phosphor Bronze | Down | Jack | Surface Mount | 8p8c (RJ45 Ethernet) | 1 | Board Lock | 90 ° |
