PCN2-S24 Series

Isolated DC/DC Converters - Through Hole 21.6-26.4Vin +/-5V +/-200mA 2W Iso SIP

Manufacturer: CUI Inc.

Catalog

Isolated DC/DC Converters - Through Hole 21.6-26.4Vin +/-5V +/-200mA 2W Iso SIP

Part	Power (Watts)	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Features	Voltage - Isolation	Current - Output (Max) [Max]	Standard Number	Number of Outputs	Efficiency	Package / Case	Type	Approval Agency	Voltage - Input (Max) [Max]	Mounting Type	Voltage - Output 1	Voltage - Input (Min) [Min]	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2
CUI Inc. PCN2-S24-S12-S	2 W	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	-40 C	100 °C	ITE (Commercial)	SCP	1000 V	167 mA	55032 Class A	1	81 %	6-SIP Module 4 Leads	Isolated Module	EN	26.4 V	Through Hole	12 V	21.6 V
CUI Inc. PCN2-S24-D12-S	2 W	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	-40 C	100 °C	ITE (Commercial)	SCP	1000 V		55032 Class A	2	81 %	6-SIP Module 5 Leads	Isolated Module	EN	26.4 V	Through Hole	12 V	21.6 V	83 mA	83 mA	-12 V
CUI Inc. PCN2-S24-S15-S	2 W	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	-40 C	100 °C	ITE (Commercial)	SCP	1000 V	134 mA	55032 Class A	1		6-SIP Module 4 Leads	Isolated Module	EN	26.4 V	Through Hole	15 V	21.6 V
CUI Inc. PCN2-S24-D5-S	2 W	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	-40 C	100 °C	ITE (Commercial)	SCP	1000 V		55032 Class A	2	79 %	6-SIP Module 5 Leads	Isolated Module	EN	26.4 V	Through Hole	5 V	21.6 V			-5 V

Isolated DC/DC Converters - Through Hole 21.6-26.4Vin +/-5V +/-200mA 2W Iso SIP
