MSM SERIES 19MM METAL LINE SWITC
| Part | Mechanical Life | Electrical Life | Actuator Marking | Color - Actuator/Cap | Mounting Type | Panel Cutout Dimensions [diameter] | Illumination Voltage (Nominal) | Actuator Type | Voltage Rating - DC | Switch Function | Operating Temperature [Max] | Operating Temperature [Min] | Illumination Type, Color | Current Rating (Amps) | Ingress Protection | Circuit | Type | Termination Style | Features | Voltage Rating - AC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 1500000 Cycles | 200000 Cycles | No Marking | Clear | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | 30 V | On-Mom | 85 °C | -25 °C | Blue Green LED Red | 100 mA | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | Ceramic Actuator | |
 SCHURTER Inc. | 1500000 Cycles | 50000 Cycles | No Marking | Clear | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | On-Mom | 85 °C | -25 °C | Blue Green LED Red | 10 A | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | Ceramic Actuator | 250 V | |
 SCHURTER Inc. | 1500000 Cycles | 200000 Cycles | No Marking | Silver | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | On-Mom | 85 °C | -25 °C | Blue LED | 5 A | IP40 | DPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 125 V | ||
 SCHURTER Inc. | 1500000 Cycles | 200000 Cycles | No Marking | Silver | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | On-Mom | 85 °C | -25 °C | LED Red | 5 A | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 125 V | ||
 SCHURTER Inc. | 1500000 Cycles | 50000 Cycles | No Marking | Silver | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | On-Mom | 85 °C | -25 °C | LED Red | 10 A | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 250 V | ||
 SCHURTER Inc. | 1500000 Cycles | 200000 Cycles | No Marking | Silver | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | 30 V | On-Mom | 85 °C | -25 °C | LED Red | 100 mA | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | ||
 SCHURTER Inc. | 1500000 Cycles | 50000 Cycles | No Marking | Silver | Panel Mount Front | 19.1 mm | 24 V | Button Flush Round | On-Mom | 85 °C | -25 °C | Blue LED | 10 A | IP40 | SPDT | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 250 V |
