LCG H9RM Series
Manufacturer: ams-OSRAM USA INC.
Beta
⌘K
LED OSRAM OSTAR GREEN 550NM SMD
| Part | Thermal Resistance of Package | Current - Max [Max] | Color | Viewing Angle | Package / Case | Package / Case | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Supplier Device Package | Lumens/Watt @ Current - Test | Temperature - Test | Luminous Flux @ Current/Temperature | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Mounting Type | Voltage - Forward (Vf) (Typ) | Current - Test | Wavelength [Min] | Wavelength [Max] | Luminous Flux @ Current/Temperature [Min] | Luminous Flux @ Current/Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ams-OSRAM USA INC. | 20 °C/W | 500 mA | Green | 120 ° | 3838 Metric | 1515 | 0.148 in | 0.148 in | 3.75 mm | 3.75 mm | SMD | 126 lm/W | 25 °C | 146 lm | 0.6 mm | 0.024 in | Surface Mount | 3.3 V | 350 mA | 500 nm | 600 nm | ||
 ams-OSRAM USA INC. | 500 mA | Green | 120 ° | 3838 Metric | 1515 | 0.148 in | 0.148 in | 3.75 mm | 3.75 mm | 2-SMD | 120 lm/W | 25 °C | 139 lm | 0.6 mm | 0.024 in | Surface Mount | 3.3 V | 350 mA | 97 lm | 180 lm |
