9685 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 3COND 22AWG CHRM SHD
| Part | Shield Coverage | Shield Material | Conductor Material | Usage | Wire Gauge | Operating Temperature [Min] | Operating Temperature [Max] | Cable Type | Jacket Color | Length | Length | Conductor Insulation | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Features | Shield Type | Conductor Strand [custom] | Conductor Strand [custom] | Ratings | Number of Conductors | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Copper Tinned | Computer | 22 AWG | -20 ░C | 60 °C | Multi-Conductor | Chrome | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) | 0.813 mm | 0.032 in | 5.06 mm | 0.199 in | Poly-Vinyl Chloride (PVC) | Drain Wire | Foil | 30 AWG | 7 | UL Style 2919 | 3 | 300 VDC |
