M2024TY Series

Catalog

MINIATURE ROCKER/MULTI-FUNCTION

Part	Electrical Life	Mechanical Life	Circuit	Termination Style	Mounting Type	Actuator Type	Color - Actuator/Cap	Voltage Rating - AC	Switch Function	Features	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Actuator Marking	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - DC	Approval Agency
NKK Switches M2024TYW01-HB	25000 Steps	50000 Cycles	SP3T	Solder Lug	Flange Panel Mount	Paddle	White	125 V	On-On-On	Jumper needed to achieve triple throw	16 mm	28.5 mm	No Marking	3 A 6 A	85 °C	-30 ░C	30 V	CSA UL
NKK Switches M2024TYW01-JA	25000 Steps	50000 Cycles	SP3T	Solder Lug	Flange Panel Mount	Concave	Black	125 V	On-On-On	Jumper needed to achieve triple throw	16 mm	28.5 mm	No Marking	3 A 6 A	85 °C	-30 ░C	30 V	CSA UL
NKK Switches M2024TYW01	25000 Steps	50000 Cycles	SP3T	Solder Lug	Flange Panel Mount	Actuator Arm Cap Required		125 V	On-On-On	Jumper needed to achieve triple throw	16 mm	28.5 mm	Varies by Cap	3 A 6 A	85 °C	-30 ░C	30 V	CSA UL
