M80-5L2 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN HEADER R/A 4POS
| Part | Features | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Style | Shrouding | Insulation Color | Row Spacing - Mating | Row Spacing - Mating | Insulation Height | Insulation Height | Number of Rows [custom] | Termination | Contact Shape | Contact Type | Contact Finish - Mating | Voltage Rating | Number of Positions Loaded | Insulation Material | Material Flammability Rating | Connector Type | Number of Positions [custom] | Number of Positions [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Contact Length - Post | Contact Length - Post | Current Rating (Amps) | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Keying Slot Mating Flange Mounting Flange Mounting Hardware | 29.5 µin | 0.75 µm | Board to Cable/Wire | Shrouded - 4 Wall | Black | 2 mm | 0.079 in | 5.55 mm | 0.218 in | 2 | Solder | Circular | Male Pin | Gold | 800 V | All | Polyphenylene Sulfide (PPS) Glass Filled | UL94 V-0 | Header | 4 | 2 | -55 C | 125 °C | Threaded | 4.5 mm | 0.177 in | 2.2 A | Right Angle Through Hole |
