337-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Read Out | Card Type | Color | Mounting Type | Contact Type | Number of Positions/Bay/Row | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Pitch | Pitch | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Termination | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Solder | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Right Angle Through Hole | Cantilever | 25 | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Right Angle Through Hole | Cantilever | 25 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Solder | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Solder | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Non Specified - Single Edge | Green | Through Hole | Cantilever | 25 | Copper Alloy | 0.156 " | 3.96 mm | -40 C | 105 ░C | Female | 3.96 mm | 0.156 in | 25 | 0.25 Ám | 10 Áin | Wire Wrap |
