2823385 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

7P,2MM,SHRD HDR,SRRT,2.8,SN,TB

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Current Rating (Amps)	Shrouding	Material Flammability Rating	Number of Rows	Insulation Height [custom]	Insulation Height [custom]	Mounting Type	Voltage Rating	Contact Material	Fastening Type	Number of Positions Loaded	Contact Type	Pitch - Mating [x]	Pitch - Mating [x]	Contact Length - Mating	Contact Length - Mating	Number of Positions	Insulation Material	Contact Finish - Post	Insulation Color	Connector Type	Contact Length - Post [x]	Contact Length - Post [x]
TE Connectivity Raychem Cable Protection 2823385-7	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	7	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 2823385-3	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in		Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 2823385-5	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in		Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 2823385-2	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	2	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 1-2823385-2	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	12	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 2823385-4	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	4	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 2823385-9	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	9	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
TE Connectivity Raychem Cable Protection 1-2823385-0	0.3 µm	12 µin	Square	-40 °C	105 ░C	118.1 µin	3 µm	Solder	2 A	Shrouded - 2 Wall	UL94 V-0	1	0.157 in	4 mm	Through Hole Right Angle	125 VAC	Phosphor Bronze	Detent Lock	All	Male Pin	0.079 in	2 mm	4 mm	0.157 in	10	Thermoplastic	Tin	Black	Header	0.11 in	2.8 mm
