325-060 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 60POS 0.100
| Part | Material - Insulation | Termination Rows | Card Type | Number of Rows | Termination | Color | Gender | Read Out | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Contact Material | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Flange Feature | Number of Positions | Contact Finish | Card Thickness | Card Thickness | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 1 | Wire Wrap | Green | Female | Single | 0.25 Ám | 10 Áin | 60 | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Wire Wrap | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Solder | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 1 | Solder | Green | Female | Single | 0.25 Ám | 10 Áin | 60 | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | ||||||
EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Solder | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 1 | Wire Wrap | Green | Female | Single | 0.25 Ám | 10 Áin | 60 | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | Flush Mount Top Opening Unthreaded | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 0.16 " | 4.06 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Solder Eyelet(s) | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | Flush Mount Top Opening Unthreaded | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | 0.16 " | 4.06 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 1 | Solder Eyelet(s) | Green | Female | Single | 0.25 Ám | 10 Áin | 60 | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Solder | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Dual Edge | Wire Wrap | Green | Female | Dual | 0.25 Ám | 10 Áin | Copper Alloy | Cantilever | -65 ░C | 125 °C | Through Hole | Flush Mount Top Opening Unthreaded | 60 | Gold | 3.18 mm | 0.125 in | 0.1 " | 2.54 mm | 2 | 2 | 30 | 0.16 " | 4.06 mm |
