MS3102R24 Series

Manufacturer: Amphenol Aerospace Operations

Catalog

CONN RCPT FMALE 24P SOLDER CUP

Part	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Mounting Type	Termination	Grade	Contact Finish - Mating	Connector Type	Number of Positions	Primary Material	Color	Operating Temperature (Max)	Operating Temperature (Min)	Cable Opening	Shielding	Qualification	Shell Finish	Ingress Protection	Fastening Type	Mounting Feature	Shell Material	Orientation	Applications	Contact Material	Insert Material	Current Rating Options	Shell Size - Insert Length	Shell Size - Insert Width	Voltage Rating (DC)	Voltage Rating (AC)	Current Rating
Amphenol Aerospace Operations MS3102R24-28S	24	28	Panel Mount	Solder Cup	Military	Silver	Female Sockets Receptacle	24 pos	Metal	Olive Drab	125 °C	-55 °C	1.375 in	Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)
Amphenol Aerospace Operations MS3102R24-22S	24	22	Panel Mount	Solder Cup	Military	Silver	Female Sockets Receptacle	4	Metal	Olive Drab	125 °C	-55 °C	1.375 in	Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene
Amphenol Aerospace Operations MS3102R24-7P			Panel Mount	Solder Cup	Military	Silver	Male Pins Receptacle	16	Metal	Olive Drab	125 °C	-55 °C		Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)				13A 23A	24 mm	7 mm
Amphenol Aerospace Operations MS3102R24-22P	24	22	Panel Mount	Solder Cup	Military	Silver	Male Pins Receptacle	4	Metal	Olive Drab	125 °C	-55 °C	1.375 in	Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene
Amphenol Aerospace Operations MS3102R24-21P			Panel Mount	Solder Cup	Military	Silver	Male Pins Receptacle	10	Metal	Olive Drab	125 °C	-55 °C		Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene	13A 46A	24 mm	21 mm	1250 VDC	900 VAC
Amphenol Aerospace Operations MS3102R24-5S			Panel Mount	Solder Cup	Military	Silver	Female Sockets Receptacle	16	Metal	Olive Drab	125 °C	-55 °C		Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene		24 mm	5 mm			13 A
Amphenol Aerospace Operations MS3102R24-9S			Panel Mount	Solder Cup	Military	Silver	Female Sockets Receptacle	2	Metal	Olive Drab	125 °C	-55 °C	1.375 in	Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene		24 mm	9 mm
Amphenol Aerospace Operations MS3102R24-7P			Panel Mount	Solder Cup	Military	Silver	Male Pins Receptacle	16	Metal	Olive Drab	125 °C	-55 °C		Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene	13A 23A	24 mm	7 mm
Amphenol Aerospace Operations MS3102R24-3S
Amphenol Aerospace Operations MS3102R-24-11P			Panel Mount	Solder Cup	Military	Silver	Male Pins Receptacle	9	Metal	Olive Drab	125 °C	-55 °C	1.375 in	Unshielded	MIL-DTL-5015	Cadmium Olive Drab Chromate	Environment Resistant	Threaded	Flange	Aluminum Alloy	N (Normal)	Marine Military	Copper Alloy	Neoprene		24 mm	11 mm
