ECE-P2 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP ALUM 4700UF 20% 250V SNAP TH

Part	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Lead Spacing	Lead Spacing	ESR (Equivalent Series Resistance)	Tolerance	Ripple Current @ High Frequency	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Lifetime @ Temp.	Polarization	Capacitance	Ripple Current @ Low Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Height - Seated (Max)
Panasonic Industrial Automation Sales ECE-P2EP472HA	3.15 in	80 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	42 mOhm	20 %	13.51 A	General Purpose	85 °C	-40 °C	250 V	3000 Hrs	Polar	4700 µF	9.65 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2GP222HX	3.622 in		Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	90 mOhm	20 %	11.38 A	General Purpose	85 °C	-25 °C	400 V	3000 Hrs	Polar	2200 µF	8.13 A	1.969 in	50 mm	Through Hole	92 mm
Panasonic Industrial Automation Sales ECE-P2EP332HX			Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	60 mOhm	20 %	10.11 A	General Purpose	85 °C	-40 °C	250 V	3000 Hrs	Polar	3.3 mF	7.22 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2AA183HA	3.622 in		Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	17 mOhm	20 %	9.936 A	General Purpose	105 ░C	-40 °C	100 V	3000 Hrs	Polar	18000 µF	8.64 A	1.969 in	50 mm	Through Hole	92 mm
Panasonic Industrial Automation Sales ECE-P2HP821HA	2.48 in	63 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	222 mOhm	20 %	6.258 A	General Purpose	85 °C	-25 °C	500 V	3000 Hrs	Polar	820 µF	4.47 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2AA123HA	2.48 in	63 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	22 mOhms	20 %	8.246 A	General Purpose	105 ░C	-40 °C	100 V	3000 Hrs	Polar	12000 µF	7.17 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2EA392HA	3.15 in	80 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	55 mOhm	20 %	8.54 A	General Purpose	105 ░C	-40 °C	250 V	3000 Hrs	Polar	3900 µF	6.1 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2WP152HX	3.15 in	80 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	144 mOhm	20 %	8.61 A	General Purpose	85 °C	-25 °C	450 V	3000 Hrs	Polar	1.5 mF	6.15 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2EP752HA	4.134 "	105 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	26 mOhm	20 %	17.58 A	General Purpose	85 °C	-40 °C	250 V	3000 Hrs	Polar	7500 µF	12.56 A	1.969 in	50 mm	Through Hole
Panasonic Industrial Automation Sales ECE-P2WP122HX	2.48 in	63 mm	Radial Can - Snap-In - 5 Lead	25 mm	0.984 "	180 mOhm	20 %		General Purpose	85 °C	-25 °C	450 V	3000 Hrs	Polar	1.2 mF	5.43 A	1.969 in	50 mm	Through Hole
