RSF46 Series
Manufacturer: Sensata Technologies
Beta
⌘K
SENSOR LEVEL SWITCH SINGLE FLOAT
| Part | Minimum Liquid Specific Gravity [Min] | Material - Housing & Prism | Switch Actuation Level | Switch Actuation Level | Mounting Type | Type | Operating Temperature [Min] | Operating Temperature [Max] | Output Configuration | Voltage Rating | Current |
|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata Technologies | 0.85 | Polyphenylene Sulphide (PPS) | 0.945 in | 24 mm | M16x2 Thread Panel Mount | Liquid | -10 °C | 120 °C | SPST-NC/NO | 120 VDC 240 VAC | 600 mA |
 Sensata Technologies | 0.85 | Polyphenylene Sulphide (PPS) | 0.945 in | 24 mm | M16x2 Thread Panel Mount | Liquid | -10 °C | 120 °C | SPST-NC/NO | 300 VDC 300 VAC | 1 A |
