415-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN CARDEDGE HSG 17POS .200 2PC
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Note | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Color | Card Thickness | Card Thickness | Card Type | Pitch | Pitch | Termination Rows [custom] | Gender | Contact Finish | Number of Rows [custom] | Termination | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -65 ░C | 125 °C | UL94 V-0 | Contacts Not Included | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 2.36 mm | 0.093 " | Non Specified - Dual Edge | 5.08 mm | 0.2 in | ||||||||||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 1.57 mm | 0.062 in | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Solder Eyelet(s) | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 2.36 mm | 0.093 " | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Wire Wrap | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | ||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 1.57 mm | 0.062 in | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Wire Wrap | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 2.36 mm | 0.093 " | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Wire Wrap | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 1.57 mm | 0.062 in | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Solder | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 2.36 mm | 0.093 " | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Solder | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 2.36 mm | 0.093 " | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Solder Eyelet(s) | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | -65 ░C | 125 °C | UL94 V-0 | Contacts Not Included | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 1.57 mm | 0.062 in | Non Specified - Dual Edge | 5.08 mm | 0.2 in | ||||||||||
 EDAC Inc. | -65 ░C | 125 °C | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | Green | 1.57 mm | 0.062 in | Non Specified - Dual Edge | 5.08 mm | 0.2 in | 2 | Female | Gold | 2 | Wire Wrap | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Copper Alloy |
