ALS36H Series

Manufacturer: KEMET

Catalog

CAP ALUM 10000UF 63V SCREW CHAS

Part	Ripple Current @ Low Frequency	Polarization	Size / Dimension [diameter]	Size / Dimension [diameter]	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Ripple Current @ High Frequency	Tolerance [Min]	Tolerance [Max]	Voltage - Rated	Lifetime @ Temp.	Package / Case	Capacitance	ESR (Equivalent Series Resistance)	Mounting Type	Height - Seated (Max) [Max]
KEMET ALS36H103K2C063	9.5 A	Polar	50.8 mm	2 in	0.875 "	22.23 mm	2.125 in	53.98 mm	General Purpose	85 °C	-40 C	11.4 A	-10 %	30 %	63 V	18000 Hrs	Radial Can - Screw Terminals	10000 µF	32 mOhm	Chassis Mount
KEMET ALS36H103D3C050	11.7 A	Polar	34.93 mm	1.375 in	0.5 in	12.7 mm		3.125 in	General Purpose	85 °C	-40 C	15.6 A	-10 %	30 %	50 VDC	11000 Hrs	Radial Can - Screw Terminals	10000 µF	24 mOhm	Chassis Mount	79.38 mm
