629-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
629 SERIES RIGHT ANGLE D-SUB PLU
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Flange Feature | Shell Material, Finish | Number of Rows [custom] | Number of Positions | Material Flammability Rating | Shell Size, Connector Layout | Shell Size, Connector Layout | Contact Finish Thickness | Contact Finish | Connector Style | Contact Type | Termination | Features | Current Rating (Amps) | Mounting Type | Backset Spacing | Backset Spacing | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Flash | Gold | D-Sub | Signal | Solder | Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (M3) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Flash | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (Unthreaded) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Flash | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (M3) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Flash | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 15 µin | 0.38 µm | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (Unthreaded) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 15 µin | 0.38 µm | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (M3) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Board Lock Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 15 µin | 0.38 µm | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Housing/Shell (Unthreaded) | Nickel Plated Steel | 2 | 37 | UL94 V-0 | 4 | DC C | Gold | D-Sub | Signal | Solder | Grounding Indents Mounting Brackets Shielded | 3 A | Panel Mount Right Angle Through Hole | 10.4 mm | 0.409 in | Plug Male Pins | 30 Áin | 0.76 Ám |
