E0200 Series Series

Sealed Snap-acting Momentary Pushbutton Switches Pushbutton Switches ON-(ON) SPDT R/A PCB

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Sealed Snap-acting Momentary Pushbutton Switches Pushbutton Switches ON-(ON) SPDT R/A PCB

Part	Electrical Life	Voltage Rating - AC	Actuator Type	Operating Temperature [Min]	Operating Temperature [Max]	Switch Function	Voltage Rating - DC	Features	Color - Actuator/Cap	Mounting Type	Actuator Marking	Circuit	Termination Style	Type	Current Rating (Amps)
Littelfuse/Commercial Vehicle Products E121SD1V61GE	60000 Cycles	120 V	Round Plunger	-30 ░C	75 ░C	On-Mom	28 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard
Littelfuse/Commercial Vehicle Products E221SD1CLE	60000 Cycles	120 V	Round Plunger	-30 ░C	75 ░C	On-Mom	28 V	Process Sealed	White	Through Hole	No Marking	DPDT	PC Pin	Standard
Littelfuse/Commercial Vehicle Products E121SD3V31GE	60000 Cycles	120 V	Round Plunger	-30 ░C	75 ░C	On-Mom	28 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard
Littelfuse/Commercial Vehicle Products E125MD1CBE	60000 Cycles	20 V	Plunger for Cap	-30 ░C	75 ░C	On-Mom	20 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard	0.4 VA
Littelfuse/Commercial Vehicle Products E125SD1AKE	60000 Cycles	20 V	Round Plunger	-30 ░C	75 ░C	On-Mom	20 V	Process Sealed	White	Through Hole Right Angle	No Marking	SPDT	PC Pin	Standard	0.4 VA
Littelfuse/Commercial Vehicle Products E125SD1V3BE	60000 Cycles	20 V	Round Plunger	-30 ░C	75 ░C	On-Mom	20 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard	0.4 VA
Littelfuse/Commercial Vehicle Products E125SD3V3BE	60000 Cycles	20 V	Round Plunger	-30 ░C	75 ░C	On-Mom	20 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard	0.4 VA
Littelfuse/Commercial Vehicle Products E121SD1AGE	60000 Cycles	120 V	Round Plunger	-30 ░C	75 ░C	On-Mom	28 V	Process Sealed	White	Through Hole Right Angle	No Marking	SPDT	PC Pin	Standard
Littelfuse/Commercial Vehicle Products E221SD1AV2GE	60000 Cycles	120 V	Round Plunger	-30 ░C	75 ░C	On-Mom	28 V	Process Sealed	White	Right Angle Through Hole Vertical	No Marking	DPDT	PC Pin	Standard
Littelfuse/Commercial Vehicle Products E125SD1CBE	60000 Cycles	20 V	Round Plunger	-30 ░C	75 ░C	On-Mom	20 V	Process Sealed	White	Through Hole	No Marking	SPDT	PC Pin	Standard	0.4 VA

Catalog

Sealed Snap-acting Momentary Pushbutton Switches Pushbutton Switches ON-(ON) SPDT R/A PCB

Key Features

• Process sealed with disposable splashproof boot

• Snap-fitting plunger available

• Long life contact design

Description

C&K’s E020 series are sealed snap-acting momentary pushbutton switches, built for use in instrumentation and the networking and telecommunications industries. The E020 features a long-life contact design and is process-sealed with a disposable, splash proof boot. The switches also come with an optional snap-fitting plunger.
