R12541 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
CONN SMA RCP 0HZ TO 24.5GHZ 50OH
| Part | Connector Style | Contact Termination | Housing Color | Number of Ports | Impedance | Connector Type | Shield Termination | Fastening Type | Mounting Feature | Center Contact Material | Mounting Type | Frequency - Max [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Center Contact Plating | Mating Cycles | Body Material | Voltage Rating | Features | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | SMA | Solder | Silver | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper Brass | Panel Mount | 24.5 GHz | |||||||||
 Radiall USA, Inc. | SMA | Solder | Silver | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper | Panel Mount Through Hole | 18 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | Extended Insulation | |
 Radiall USA, Inc. | SMA | Compression | Silver | 1 | 50 Ohms | Female Socket Jack | Screw | Threaded | Flange | Beryllium Copper | Panel Mount | 18 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | ||
 Radiall USA, Inc. | SMA | Compression | Gold | 1 | 50 Ohms | Female Socket Jack | Screw | Threaded | Flange | Beryllium Copper | Panel Mount | 18 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | Gold | |
 Radiall USA, Inc. | SMA | Solder | Gold | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper | Panel Mount Through Hole | 18 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | Extended Insulation | Gold |
 Radiall USA, Inc. | SMA | Solder | Silver | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper | Panel Mount Through Hole | 18 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | Extended Insulation | |
 Radiall USA, Inc. | SMA | Solder | Gold | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper | Panel Mount Through Hole | 26 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 500 V | Extended Insulation | Gold |
 Radiall USA, Inc. | SMA | Solder | Gold | 1 | 50 Ohms | Female Socket Jack | Solder | Threaded | Flange | Beryllium Copper | Panel Mount Through Hole | 24.5 GHz | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Gold | 500 | Stainless Steel | 335 V | Extended Insulation | Gold |
